Mizuho OSI Trios

Mizuho OSI Trios Surgical Table System

The Mizuho OSI Trios Surgical Table System enhances the functionality of the original spinal platform with advanced features designed to meet today’s surgical demands. The Trios system is engineered for spine and imaging procedures, supporting patient weights up to 650 lbs while remaining fully radiolucent for optimal imaging. It features powered floor locks, a unique tabletop mounting interface, and a streamlined 180-degree rotation mechanism, ensuring safe and efficient transitions from supine to prone positions. The system also incorporates Tempur-Pedic Medical Pad technology for superior patient comfort and an IntelliPENDANT hand pendant that controls all table functions for precise adjustments.

Key Features

• High Weight Capacity:
  • Supports up to 650 lbs (295 kg) for both spinal and radiolucent imaging tops.
• Advanced Imaging Compatibility:
  • Carbon fiber frame ensures complete radiolucency with unrestricted C-arm and O-arm access.
• Enhanced Patient Positioning:
  • Open frame design reduces vena cava compression and minimizes epidural venous bleeding.
  • Customizable pad and component placement for individualized patient support.
• Efficient Table Controls:
  • IntelliPENDANT hand pendant and auxiliary panel control all table functions including floor locks, height, lateral roll, Trendelenburg/reverse Trendelenburg, and Return to Level.
  • Unique tabletop mounting interface and tower ratchet mechanism facilitate precise positioning and smooth 180° rotation.
• Safety & Stability:
  • Powered floor locks and advanced control pad system enhance safety during surgery by stimulating hip/thigh pressure points in prone patients.

Detailed Specifications

Trios Base (Advanced Control Base)

• Crossbar to Floor Height:
  • 33 in (83.8 cm) – 50.7 in (128.8 cm)
• Trendelenburg/Reverse Trendelenburg:
  • 10°
• Lateral Tilt:
  • 25°
• Base Dimensions:
  • Width: 110 in (279 cm)
  • Retracted Base Length: 68 in (173 cm)
• Power:
  • Voltage: 100 to 240 VAC, 50 to 60 Hz
  • Battery: Sealed lead acid; Life: 8 hours, Rechargeable in 6 hours

Trios Spinal Surgery Top

• Table Top Dimensions:
  • Length: 84 in (213 cm)
  • Width: 17 in (43 cm)
• Patient Weight Capacity:
  • 650 lbs (295 kg)

Trios Radiolucent Imaging Top

• Table Top Dimensions:
  • Length: 84 in (213 cm)
  • Width: 21.5 in (55 cm)
• Patient Weight Capacity:
  • 650 lbs (295 kg)
