Pelton & Crane Magnaclave Sterilizer

The Pelton & Crane Magnaclave is a robust, manually-operated steam sterilizer designed for heavy-duty use in medical, dental, and laboratory environments. Known for its large capacity and efficient performance, the Magnaclave features a round, stainless steel chamber and a suite of safety and clarity features to ensure secure and effective sterilization. Its quick cycle times and user-friendly operation make it a preferred choice for facilities requiring reliable, high-volume sterilization.

Key Points

• Large Capacity:
  Features a 15-inch diameter by 26-inch deep chamber, providing substantial space for sterilizing large instrument sets and other medical supplies.

• Efficient Cycle Times:
  Offers a rapid 18-minute flash cycle from a warm start and a 35-minute cycle from a cold start, enhancing throughput in busy settings.

• Advanced Safety Features:
  Includes a patented door lock system that seals the entire rim of the sterilizer, enhancing safety by ensuring a secure seal during operation.

• Indicator System:
  Equipped with a series of indicator lights for “Power On,” “Heat On,” “Sterile,” and “Open Door,” which provide clear, at-a-glance information about the sterilizer’s status.

• Easy Operation and Maintenance:
  Designed with a simple and easy locking mechanism, making it user-friendly. Its design also facilitates easy cleaning and maintenance.

Specifications

• Chamber Dimensions:

  • Diameter: 15 inches (38.7 cm)
  • Depth: 26 inches (66 cm)

• Overall Dimensions:

  • Width: 28 inches (71.1 cm)
  • Depth: 34.5 inches (87.6 cm)
  • Height (with stand): 53 inches (134.6 cm)
  • Height (without stand): 23 inches (58.4 cm)

• Minimum Space Required:

  • With Stand: 34 to 40 inches wide x 56 inches deep x 65 inches high
  • Without Stand: 34 to 40 inches wide x 56 inches deep x 35 inches high

• Power Specifications:

  • Voltage: 208 – 240 VAC
  • Power Consumption: 5000W
  • Current Rating: Requires a 30-amp electrical circuit

• Trays:

  • Small Tray: 10.5” x 26.5” x 2”
  • Large Tray: 15.25” x 26.5” x 6”
